Contact System 3S SMD Pick and Place

Place rate; max 8500cp/h Components:0402-3038 SO SOW QFP20-288 uBGA BGA Accuracy:0,002 inch Alignment: Full Vision Load System:In-line SMEMA Feeders:Tape 8-44mm Waffle trays Vibrate SO6-QFP265 Vision:2 camerasOn the Fly Heads:4 Bank 2x50 feeders

AVP 300 Full vision Screen Printer

accuracy: +/- 25 microns
Under Stencil Cleaner: Standard wet / dry.
Vision System: 2-camera system.
Field of vision (Camera field of view ): 8mm x 10mm

PCB inserter.

This machine can handle more than

1000 boards in an Hour

Rollover on one of the machines

SMD LEAD FREE production-line

Maximum more then 25.000 Cp / Hour

Contact System 3AV SMD Pick and Place

Place rate; max 9000cp/h Components:0402-3038 SO SOW QFP20-288 uBGA BGA Accuracy:0,001 inch Alignment: Full Vision Load System:In-line SMEMA Feeders:Tape 8-44mm Waffle trays Vibrate SO6-QFP265 Vision:2 camerasOn the Fly Heads:4 Bank 2x50 feeders

Contact System 3S WIDE BOARD

SMD Pick and Place

Max. board wide:850mmPlace rate; max 8500cp/h Components:0402-3038 SO SOW QFP20-288 uBGA BGA Accuracy:0,002 inch Alignment: Full Vision Load System:In-line SMEMA Feeders:Tape 8-44mm Waffle trays Vibrate SO6-QFP265 Vision:2 camerasOn the Fly Heads:4 Bank 2x30 feeder

Reflow oven Ersa Hotflow 7

Full convection Lead free forced cooling down Lead Free max. 900mm/ min.

Unloader Universal

To Buy:

2 In line Full Vision board inspection M3X
